| Main Technical data | T300V | |
| Capacity | Max.swing over bed | Φ310mm |
| Max.swing over cross slide | Φ195mm | |
| Max. swing in gap | w/o gap | |
| Distance between centers | 610mm/815mm | |
| Width of bed | 150mm | |
| Spindle | Spindle bore | Φ38mm |
Taper of spindle bore | M.T.#5 | |
Range of spindle speeds | L:45~750rpm H:120~2000rpm（stepless） | |
| Threads | Threads Metric pitches | 0.25-5mm (21)0.1-3.5mm/24kinds |
| Threads Imperial pitches | 6-96 T.P.I.(13) | |
| Threads diametral pitches | - | |
| Threads module pitches | - | |
| Feeds | Max. travel of top slide | 112mm |
| Max. travel of cross slide | 135mm | |
| Cross feeds range | 0.044-0.437mm/rev(15) | |
| Longitudinal feeds range | 0.022-0.218mm/rev(15) | |
| Tailstock | Quill diameter | Φ30 |
| Quill travel | 95mm/85mm | |
| Taper of quill | M.T.#2/M.T.#3 | |
| Motor | Motor power | 1.1kw |
| Coolant pump power | 40w | |
| Packing&others | Tool section | 12x12 |
| Packing size(L*W*H) | 1265/1465x580x620 | |
| N.W/G.W | 332.5/342.5 | |
| Standard configuration | Optional configuration |
| 3 jaw chuckΦ125mm | Working lamp |
| 4 jaw chuckΦ125mm | Coolant pump |
| Steady rest& follow rest | Footstand |
| Face plate | Chuck guard |
| Change gear sets | Leadscrew cover |
| Splash guard | Tool post cover |
| Oil tray | Live centerMT#2/3 |
| Dead center*2 | Drill chuck with arbor |
| Digital readout | |
| Face plate |
