| Main Technical data | T510（B） | T560（B） | T660（B） | |
| Capacity | Max.swing over bed | Φ510mm | Φ560mm | Φ660mm |
| Max.swing over cross slide | Φ305mm | Φ355mm | Φ455mm | |
| Max. swing in gap | Φ735mm | Φ785mm | Φ885mm | |
| Distance between centers | 1000/1500/2000/3000mm | |||
| Width of bed | 350mm | |||
| Spindle | Spindle bore | Φ80mm（Φ103mm） | ||
Taper of spindle bore | M.T.#7（Φ113，1:20） | |||
Range of spindle speeds | 12 steps 25-1600rpm（25-1500rpm） | |||
| Thread cutting | Threads Metric pitches | 47kinds，0.2-14mm（41kinds，0.1-14mm） | ||
| Threads Imperial pitches | 2-112 T.P.I. 60kinds | |||
| Threads diametral pitches | 4-112 D.P. 50kinds | |||
| Threads module pitches | 0.1-7M.P. 34kinds | |||
| Range of feeds | Max. travel of top slide | 130mm | ||
| Max. travel of cross slide | 316mm | |||
| Cross feeds range | 42kinds，0.020-0.573mm/rev | |||
| Longitudinal feeds range | 35kinds，0.059-1.646mm/rev | |||
| Tailstock | Diameter for tailstock sleeve | Φ75mm | ||
| Max. travel for tailstock sleeve | 180mm | |||
| Taper of quill sleeve | M.T.#5 | |||
| Motor | Motor power | 7.5kw | ||
| Coolant pump power | 90W | |||
| Packing&others | Tool section | 25x25mm | ||
| Packing size(L*W*H) | 2450/2900/3400/4340x1150x1740mm | |||
| N.W/G.W | 2160/2550kg,2285/2690kg,2560/2980kg,2930/3410kg | |||
| Standard configuration | Optional configuration |
| Φ80mm spindle bore | Φ103mm spindle bore |
| 3 jaw chuckΦ320mm | Chuck guard |
| 4 jaw chuckΦ400mm | Leadscrew cover |
| Steady rest& follow rest | Tool post cover |
| Working lamp | Live center |
| Face plate | Drill chuck with arbor |
| Casting iron stand | Taper turning attachment |
| Coolant pump | Digital readout(2Axis/3Axis) |
| Brake system | Quick change tool post |
| Rapid feed system |
